Horizontal tmr mixer
horizontal tmr mixer is a kind of equipment that uses the principle of rapid rotation to achieve uniform mixing.
Features: The materials in the hopper are transported to the upper end of the barrel body through the spiral spindle, and then fall in an umbrella shape and continue to circulate stirring, so as to achieve the purpose of uniform mixing.
horizontal tmr mixer Function: with automatic operation timing, overload protection, feeding limit alarm and other functions; It has the advantages of less space, large capacity, low power consumption, manual saving, convenient control, fast and uniform mixing. Can be widely used in: plastic sheet material, crushing material, plastic particles, plastic old and new material and add color master stirring evenly and other purposes.
horizontal tmr mixer Applicable customers: granulation, plastic granulation, color master manufacturing, plastic modification, recycling processing, large injection molding and other industries.
Use the rapid rotation of the screw to lift the raw material from the bottom of the barrel body from the center to the top, and then fly and scatter in an umbrella shape, back to the bottom, so that the raw material in the barrel up and down stirring, a large number of raw materials can be evenly mixed in a short time.
horizontal tmr mixer product Advantages:
1.automatic operation timing, overload protection, feeding limit alarm and other functions;
2.and has the advantages of less land, large capacity, low power consumption, save labor, easy control, mixing fast and uniform;
3.can be widely used for plastic sheet material, crushing material, powder material, plastic particles, plastic old and new material and add color master stirring evenly and other purposes.
4.suitable for customers: cutting grain, plastic material, color master manufacturing, plastic modification, recycled material recycling processing, large injection molding and other industries.
horizontal tmr mixer Performance Features:
1.stirring and drying synchronization, because the material in the drying process, continue to maintain the flow state, heat penetration is uniform, drying time is short and not easy to fast;
2. the standard model for double barrel design (economic type for single layer design), the inner layer for the material contact part is all stainless steel material manufacturing; Middle sandwich installation and special insulation materials, so can achieve safety, energy saving effect;
3.with high frequency heater, heating fast, less power consumption, per ton of material drying comprehensive cost of more than 20 yuan per ton;
4.special double pipe wet discharge port, can effectively discharge moisture, collect dust, do not pollute the working environment;
5.the barrel body is equipped with an entrance door, color change refueling cleaning is simple and fast;
6.after special modification, the standard model can be easily used for plastic powder material, PET sheet crystal drying purpose;
7.more models, large capacity, standing one-time loading :0, 5T, 1 ton, 1.5 tons, 2 tons, 3 tons, etc.
8.drying mixing function two in one, when there is no need to dry, just turn off the heating switch and fan switch, standard models can be used for plastic mixing homogenization, one machine two use.
1. An empty run test should be conducted before use
2. Empty operation test. The large plastic vertical mixer can be put into production only when no abnormal sound, high heat of bearing gear, temperature helicopter of reducer and other adverse phenomena are found. Before the test, check the robustness of all the connecting parts of the large plastic vertical mixer, the amount of lubricating oil in the reducer and the integrity of the electrical equipment, and then close the main switch, pass the power supply, and carry out the empty operation test machine.
3. In operation, if it is necessary to shovel and scrape the materials of the barrel wall of the machine, use bamboo and wood tools, do not use hands, so as not to cause hand injury accidents.
4. If abnormal vibration or abnormal sound is found in the use of the machine, the large plastic stand mixer should be stopped immediately for a comprehensive inspection.
5. The use of load is not too large, generally measured by the load of the motor, with 380V motor in stirring plastic heavy current, not more than 6 amperes as normal, such as more than the load should be immediately reduced stirring capacity.
6. The shaft seal at both ends of the mixing screw should be kept clean, so as not to cause black and deterioration of plastic. There are square holes in the outer file at both ends of the large mixing barrel body, which should be unobstructed.
7. Managers must be familiar with the technical performance, internal structure, control structure and application principle of large plastic stand mixers. During operation, do not leave the work place to prevent failure and damage to parts, on the premise of ensuring safe production.
8. Turn on the power supply, open the cover of the color mixing machine, hold down the safety switch with your hand, and then press the green start switch. Pay attention to the motor steering (clockwise rotation).
9. After confirming that the motor steering is correct, it can be put into production normally. Please set the time according to the color mixing time required by different materials (the timer can be adjusted from 0 to 30 minutes) for production and use.
1. Ensure that the voltage and frequency of the power supply match the label attached to the nameboard of the manufacturer.
2. Connect cables and ground cables in accordance with local rules and regulations.
3. Use independent cable and power switch, the diameter of the wire should not be less than the wire used in the electric control box.
4. The wiring end should be safe and firm.
5. This series of power supply adopts three-phase four wire, power supply (L1, L2, L3) connected to power supply live wire, and zero wire.
6. Distribution requirements: main supply voltage :±5% Main supply frequency :±2%.
